Big Boy 4014 Locomotive Laser Cut Files: Advanced Wooden Model

$10.66 $15.23

Instant Digital Download

(41)

Build a Union Pacific Big Boy 4014 locomotive with approximately 600 parts. This advanced project is designed for a detailed, multi-session model build.

This is a digital download for making the design yourself. No physical item, plywood or hardware is shipped.

WHAT YOU RECEIVE
- SVG, DXF design files
- PDF assembly instructions
- Additional download information in a TXT file

Supplied cutting formats by material version:
- 1/8 inch: DXF
- 3 mm: DXF, SVG

PROJECT DETAILS
Finished size with 3 mm material: 870 × 109 × 170 mm (length × width × height).
Designed for 3 mm and 1/8 inch plywood. Segmented parts do not exceed approximately 260 mm. A PDF assembly guide is included.
The tender is a separate listing in the Trains section. See the download contents for the formats supplied for each material version.

BEFORE YOU CUT
Check that your laser software can open the supplied formats and that the layout fits your work area. Use the supplied version that matches your actual material thickness.

If you uniformly enlarge a slotted model, its slots and tabs enlarge too, so proportionally thicker plywood is required. For example, scaling a 3 mm design to 150% requires approximately 4.5 mm actual plywood thickness. Scale all parts equally; the finished dimensions also change. Measure your material and test the fit and kerf before cutting the full project. Message me if you need help with sizing.

USAGE TERMS
For personal use. Contact 21CNCStudio before using this design commercially or selling finished items. Do not resell, share or redistribute the digital files without permission.
